The Square Golf OMNI Portable Golf Launch Monitor is here! In this video we do a full unboxing, talk about specs, newly discovered data specifics, plus test with shot shaping, chipping, putting, and even driver! Buy the Square Golf Launch Monitor using my link & discount code below for the best price!
Exclusive Discount Code: GSVSQUARE
https://3d47a8-a6.myshopify.com/?ref=GSVSQUARE
Square Golf OMNI Quick Fact Sheet
Core Hardware
Model: SQGOE300A
Edition: OMNI Edition
Camera system: 4 high-speed cameras
Display: Built-in LCD screen
Connection: Bluetooth 5.1 Low Energy
App support: iOS, Android, Windows PC
Can operate without app: Yes
Club data requires app: Yes
Battery / Power
Battery type: Replaceable lithium-ion
Battery voltage: 14.4V
Battery capacity: 5,000mAh
Battery life: 5–7 hours
Full charge time: About 6 hours
Power input: DC 20V / 3.0A
Average current: 1,200mA
Hitting Zone / Setup
Ready zone size: 25 cm x 25 cm
Approx. hitting zone: 10″ x 10″
Ball position from unit: 35 cm / 14″ in front
Side offset from unit: 5 cm / 2″
Best club-data ball position: Front portion of ready zone
Rear of ready zone warning: Club image may not be captured
Works if ball/unit height differs: Yes, but ready zone may shrink
Tilt compensation: Yes, but too much tilt may shrink ready zone
Alignment
Alignment tool included: Yes
Alignment stick distance: 35–60 cm / 14–24″ in front of unit
Target line adjustment range: Up to ±5°
Default target line: Parallel to front face of unit
Measured Ball Data
Ball speed: Measured
Launch direction: Measured
Launch/elevation angle: Measured
Backspin: Measured
Sidespin: Measured
Carry distance: Displayed, likely calculated from measured launch data
Measured Club Data
Club path: Measured
Attack angle: Measured
Club speed: Measured
Impact point: Measured
Face angle: Estimated
Dynamic loft: Estimated
Measurement Ranges
Shot ball speed: 4–200 mph
Putting ball speed: 1–45 mph
Launch direction: -15° to +15°
Launch/elevation angle: -10° to 70°
Backspin: -4,000 to 12,000 rpm
Sidespin: -7,000 to 7,000 rpm
Club path: -20° to +20°
Attack angle: -20° to +20°
Club speed: 0–140 mph
Impact point: -40 mm to +40 mm
Sticker Requirements
Ball data: No stickers required
Club path: Shaft sticker required
Attack angle: Shaft sticker required
Club speed: Shaft + face sticker required
Impact point: Shaft + face sticker required
Face angle: Estimated, stickers required
Dynamic loft: Estimated, stickers required
Golf Ball Notes
Marked ball required: No
Recommended ball: Standard white golf ball
Possible tracking issues: Very bright, dark, matte, or heavily patterned balls
Outdoor / Durability
Indoor use: Yes
Outdoor use: Yes
Water resistance: IP44
Waterproof: No
Do not use in: Rain, heavy moisture, standing water
Avoid: Direct sunlight into cameras
Chapters:
00:00 Square OMNI Intro
01:00 OMNI Price & vs HE
01:49 What’s in the Box
04:30 OMNI Hitting Zone
05:00 Club Data & Stickers
06:35 Measured Ball Data
07:38 Club Stickers
08:22 Alignment Stick
11:37 Power Adapter
12:33 Close Up & Damage Protection
13:45 Test Shots on Square Software
24:50 Toe & Shank Impact Test
29:30 Driver Test on GSPro
31:06 GSPro Chip Test
36:05 Putting Test on GSPro
42:30 Final Thoughts
